Creality CR-M4 3D Printer

•  Extra Large Build Volume: 450 x 450 x 470mm
• Max Print Temp: 300°C
• Max Bed Temp: 100°C
• Precise double Y-axis linear rails
• All-metal “Sprite” Direct Dual-Gear Extruder & High-flow hotend
• High compatibility with filaments
• Automatic 25-point levelling and Z offset
• Special PC coating for good adhesion;
• Industrial 800-watt power supply
• Remote monitoring and remote acces
• Print Farm and multi-printer control

Other features:

• Recovery from power failure
• Filament runout sensor
• Practical cable chain against cable tangles
• Quiet motherboard (50 dB)
• Questions & Answers about Creality CR-M4
• 4020 fan for model cooling
• Flexible PC spring steel build surface and fast heating bed
• User-friendly touch screen

QUASI-INDUSTRIAL LARGE FORMAT 450*450*470mm

Creality CRM4 3d printer allows for the creation of bigger and more complex models with fewer or no post-processing requirements, which can save a lot of time and effort for users. The ability to batch-print multiple parts in one go is also a significant advantage, as it can increase efficiency and productivity, making it ideal for prototyping and small production runs. Combined with a 42-60 Y Axis stepper motor, the CR-M4 can handle a whopping 30kg print on its build plate.

The double linear rail of the Y-axis, with a 42-60 Y Axis stepper motor

The printer features CNC-machined linear rails made of bearing steel. The rails are wear-resistant and can withstand heavy loads. The linear rails on the Y axis helps move the heavy bed, has a load capacity of 30 kg; The powerful motor ensures 720 h or 30 days of constant pressure.

All-metal “Sprite” Direct Dual-Gear Extruder & High-flow hotend & 4020 fan for model cooling

The all-metal “Sprite” direct dual-gear extruder developed by Creality CR-M4 for home use is a dual-gear design that allows for smooth filament feeding and discharging with a thrust of up to 80 N.  The extruder is ideal for printing flexible filaments such as TPU. The hotend has been optimised with a high-flow nozzle and a 50-watt heating cartridge. This completely melts filament at 300 °C, even with a filament with very high-temperature resistance, it guarantees a fluid feed. The high-flow nozzle is interchangeable with a 0.6 and 0.8 mm nozzle. A special independent 4020 fan ensures that freshly printed layers, parts and components solidify faster and do not warp.

High compatibility with filaments

The printer is compatible with a variety of materials including PLA, PA (nylon), heat-resistant ABS, PLA-WOOD, PLA-CF, flexible TPU and PETG!

Automatic 25-point levelling and Z offset

Fully automatic leveling with CR Touch by probing 25 points for the largest auto-leveling 3d printer, and Z offset at 0.05mm accuracy to quickly calibrate the distance between the nozzle and the build surface.

Easy to Print:  Multiple Printing Options

The new CRM4 Creality 3d printer gives you a variety of printing options with Cloud Printing capabilities through Creality Cloud software as well as USB-A drive, USB-C cable, RJ45 LAN, and Wi-Fi connections.

Specifications:

• Printing Technology: FDM
• Build Volume: 450mm x 450mm x 470mm (17.7″ x 17.7″ x 18.5″)
• Product Dimensions: 655mm x 700mm x 865mm (25.8″ x 27.6″ x 34″)
• Net Weight: 49.6 lbs (22.48 kg)
• Gross Weight: 62.4lbs(28.3 kg)
• Printing Speed: ≤120mm/s
• Printing Accuracy: ±0.1mm
• Layer Height: 0.05-0.35mm
• Extruder Type: “Sprite” dual-gear direct drive extruder
• Extruder Material: All metal
• Filament Diameter: 1.75mm
• Z-axis Count: 2
• Nozzle Type: Brass nozzle
• Nozzle Diameter: Standard 0.4mm (compatible with 0.6/0.8mm)
• Max Print Temp: 300°C
• Max Bed Temp: 100℃
• Build Surface: PC spring steel sheet
• Display Screen: 4.3-inch color touch screen
• Mainboard: Integrated 32-bit silent mainboard
• Power Loss Recovery: Yes
• Filament Runout Sensor: Yes
• Multi-printers Control: Yes
• Sleep Mode: Yes
• Rated Voltage: 100-240V~，50/60Hz
• Rated Power: 800W
• Slicing Software: Creality Print, Creality Slicer, Cura
• File Formats: STL, OBJ, AMF
• Supported Filaments: PLA, PETG, TPU, ABS, PLA-Wood, PA, PLA-CF
• UI Languages: English, Spanish, German, French, Russian, Portuguese, Italian, Turkish, Chinese
